IrisFH/FZ5 Processing Item Function Reference Manual
697
4
Support Inspection and Measurement
Region Setting (Iris)
Set the range of iris adjustment.
1 In the Item Tab area, click [Region setting].
2 Click [Edit].
The figure setting area is displayed.
3 Specify the range of iris adjustment.
The rectangle covering the entire screen is set. Adjust the size and position of the rectangle.
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
Output Parameter (Iris)
Specifies whether or not the judgement results of this processing unit is reflected in the scene overall judgement.
1 Click [Output parameter] in the Item Tab area.
2 Choose whether or not to reflect this in the scene overall judgement in "Reflect to overall
judgement" area.
Key Points for Test Measurement and Adjustment (Iris)
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
In range Percentage inside the valid brightness range
R average R average in the region
G average G average in the region
B average B average in the region
