Extract Color Filter
530
FH/FZ5 Processing Item Function Reference Manual
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
Output Image (Extract Color Filter)
Key Points for Test Measurement and Adjustment (Color Extraction Filter)
The image specified in the Sub-image number in image display setting is displayed in the image display area.
Measurement Results for Which Output Is Possible (Extract Color Filter)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Extract Color Filter)
Setting item
Set value
[Factory default]
Description
Output image setting
• [Binary image]
• All color image
This sets the state of the image output.
Sub image number. Explanation of image to be displayed
0 Color extraction image
1 Measurement image
Measurement items Character string Description
Judge JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
120 Fill profile Set/Get
0: OFF
1: Fill profile
2: Filling up holes
121 Inverse area presence Set/Get
0: OFF
1: ON
122 Image kind Set/Get
0: Measurement image
1: All color image
2: Selection color image
3: Binary image
123 Multiple selections Set/Get
0: Multiple selections disabled
1: Multiple selections enabled
124 Output image Set/Get
0: Binary image
1: All color image
130 + 10 × N
(N = 0 to 7)
Usage flag [N]
(N = 0 to 7)
Set/Get
0: Not used
1 : Used
Default value 1 only for [0]
Default value 0 for all others
To Next Page
