Classification
220
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Classification)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Classification)
The following content is displayed in the "Detail result" area as text.
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordinate values
to exte
rnal de
vices before or after the position compensation is
applied.
Calibration
• [OFF]
•ON
Select whether to reflect the calibration
in
the values output to the
external device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Index Index No. of the biggest correlation
Model number Model No. of the biggest correlation
Correlation value Correlation value with the model
Position X X coordinate of the position where th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Angle θ Angle of the position where the model is detected
Important
