Camera Image Input FHFH/FZ5 Processing Item Function Reference Manual
45
1
Input image
Settings Flow (Camera Image Input FH)
To set camera image input, follow the steps below.
List of Camera Image Input FH Items
Item name Description
Camera 0 to 7 Select the camera to be set.
Select camera When multiple cameras are connected, select the
camera
to use for measurement.
Camera setting
Specify the camera settings such as the shutter speed or electronic flash.
Reference: Camera Settings (Camera Image Input FH) (p.46)
Screen adjust
Set the adjustment of the lighting and the lens.
Reference: Screen Adjustment Settings (Camera Image Input FH) (p.54)
White balance
When using a color camera, set the white balance.
Reference: White Balance (Camera Image Input FH) (p.64)
Calibration
Set when measurements (camera coordinate measuremen
t values) are to be output using
actual dimensions. Select the calibration setting method and generate the calibration
parameters.
Reference: Calibration (Camera Image Input FH) (p.66)
Set as necessary.
Select the camera to set
*Always do this when using multiple cameras
Check results/make adjustments
▲
Camera Selection (Camera Image Input FH)
▲
Camera Settings (Camera Image Input FH)
▲
Screen Adjust Settings (Camera Image Input FH)
▲
White Balance (Camera Image Input FH)
▲
Calibration (Camera Image Input FH)
Start
Settings complete
Test measurement
To Next Page
