Ec Corner
198
FH/FZ5 Processing Item Function Reference Manual
When the processing speed is slow
When judgement is NG
Measurement Results for Which Output Is Possible (Ec Corner)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Parameter to be adjusted Troubleshooting
Region setting Specify as small a value as possible for FigureInfo=Region.
Measurement
Minimize the distance between the upper and lower limits of line length range for extracting
lines.
Minimize the distance between the upper and lower limits of overrun range for extracting
corners.
Minimize the distance between the upper and lower limits of length range for extracting
cor
n
ers.
Minimize the distance between the upper and lower limits of angle range for extracting corners.
State Parameter to be adjusted Troubleshooting
There are lines but they are
no
t detected
Corner extraction
Expand and extend the overrun range in both the positive di
rection
and negative direction so that corners can be formed.
Measurement
items
Character
string
Description
Judge JG Judgement result
Corner X X Corner coordinate X
Corner Y Y Corner coordinate Y
Angle TH Formed angle of measured corner
Number of
detections
CT Number of detections
Reference X SX Reference X
Reference Y SY Reference Y
Corner XN
(N = 0 to 99 )
XN Corner coordinate XN
Corner YN
(N = 0 to 99)
YN Corner coordinate YN
Angle N
(N = 0 to 99)
THN Formed angle N of measured corner
Angle N of line 0
(N = 0 to 99)
DIRLN Inclination N of line 0
Angle N of line 1
(N = 0 to 99)
DIRRN Inclination N of line 1
