Omron fh-3 series - External Reference Tables (Stripes Removal Filter II)

Stripes Removal Filter IIFH/FZ5 Processing Item Function Reference Manual
539
3
Compensate image
External Reference Tables (Stripes Removal Filter II)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (not yet measured)
1: Judgement result OK
-1: Judgement result NG
120 Correction method Set/Get
0: Thick striped pattern suppression
1: Thin striped pattern suppression
121 Direction Set/Get
0: Vertical and horizontal
1: Horizontal
2: Vertical
3: Slant (upper right)
4: Slant (lower right)
122 Filter Size Set/Get 3 to 63
123 Defect brightness Set/Get
0: Light and dark
1: Light
2: Dark
124 Gain Set/Get 1 to 63
125 Offset Set/Get 0 to 255
200
Transfer source image
n
u
mber
Set/Get 0 to 9
201
Image number after
tran
sfer
Set/Get 0 to 9
202 Ta rg et image Set/Get
0: Camera input image
1: Previous. unit image
203 Display image Set/Get
0: Display the image before processed.
1: Display the image after processed.
