Detection Point
812
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Detection Point)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Detection Point)
Measurement
items
Character
string
Description
Judge JG Judgement result
Position X X X coordinate of the detection position to be retained
Position Y Y Y coordinate of the detection position to be retained
Angle TH Detection angle to be retained
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Position X Get only -99999.9999 to 99999.9999
6 Position Y Get only -99999.9999 to 99999.9999
7 Angle Get only -180 to 180
120 Method Set/Get
0: Nearest unit
1: Expression
121 Position X Set/Get Exp. character string
122 Position Y Set/Get Exp. character string
123 Angle Set/Get Exp. character string
