Camera Image Input HDR
72
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Camera Image Input HDR)
To set camera image input HDR, follow the steps below.
Camera Image Input HDR Item List
Item name Description
Camera setting
Specify the camera settings such a
s the electronic flash.
The setting method is the same as for [Camera Image Input]. Please check it.
Reference: Camera Settings (Camera Image Input HDR) (p.73)
HDR setting
Carry out the image combination and photography settings.
Reference: HDR Settings (Camera Image Input HDR) (p.76)
Bright adjust
Specify the brightness follo
w-up adjustment setting.
Reference: Bright Adjust Setting (Camera Image In
put HDR) (p.78)
Screen adjust
Adjust the lighting and the lens.
The setting method is the same as for [Camera Image Inpu
t]. Please check it. However, the iris cannot
be adjusted.
Reference: Screen Adjustment Settings (Camera Image Input) (p.30)
White balance
When using a color camera, adjust the white balance.
The setting method is the same as for [Camera Image Input]. Please check it.
Reference: White Balance (Camera Image Input) (p.38)
Calibration
Set when measurements (camera coordinate measurement va
lue
s) are to be output using actual
dimensions. Select the calibration setting method and generate the calibration parameters.
The setting method is the same as for [Camera Image Input]. Please check it.
Reference: Calibration (Camera Image Input) (p.39)
Be sure to perform settings
Start
Settings complete
Results confirmation/adjustment
▲
Camera Settings (Camera Image Input HDR)
▲
HDR Settings (Camera Image Input HDR)
▲
Bright Adjust Setting (Camera Image Input HDR)
▲
Screen Adjustment Settings (Camera Image Input)
▲
White Balance (Camera Image Input)
▲
Calibration (Camera Image Input)
Test measurement
