Fine MatchingFH/FZ5 Processing Item Function Reference Manual
387
2
Inspecting and Measuring
Output Parameters (Fine Matching)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Fine Matching)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is displayed in the Image Display area.
Defect pos X -99999.9999 to 99999.9999
Specify the X and Y axis move ranges for the center of gravity
positions that are judged to be OK.
When the "Labeling" is used, the center of gravity position of
the
l
abel number will be specified instead.
Defect pos Y -99999.9999 to 99999.9999
Specify the X and Y axis move ranges for the center of gravity
p
o
sitions that are judged to be OK.
When the "Labeling" is used, the center of gravity position of
the
l
abel number will be specified instead.
• Defect coordinates give the center of gravity position
of detected defects.
• After setting up the measurement parameters, changing the output pa
rameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordinate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Enables choosing whether or not the judgement results of this processing
unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Quantity Number of defects
Area Defect area
Defect coordinate X Defect coordinate X
Defect coordinate Y Defect coordinate Y
Sub image number. Explanation of image to be displayed
0 Measurement image
1 Difference image display
Setting item Set value Description
Note
Important
