Precise Defect
368
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Precise Defect)
Precise Defect settings are made with the following flow.
List of Precise Defect Items
Item name Description
Region setting
This item is used to set up the measurement area.
Instead of measuring the entire input image, narrowing the measurement area shortens the processing
time.
Reference: Region Setting (Precise Defect) (p.369)
Mask setting
Set it when masking a region.
The measurement result of another processing item
can also be used for masking.
Reference: Mask Setting (Precise Defect) (p.370)
Measurement
This item specifies the judgement condition for measurement results. Measurement parameters can be
changed as needed to address unstable measurement results or to increase the processing speed.
Normally, the factory default value will be used.
Reference: Measurement Parameters (Pr
ecise Defect) (p.372)
Judgement
condi
tion
This item can be changed if necessary. Normally, the factory default value will be used.
This item specifies the judgement con
d
ition for measurement results.
Reference: Judgement Condition (Precise Defect) (p.374)
Output
pa
rameter
This item can be changed if necessary. Normally, the factory default value will be used.
Use the output parameter to specify how to handle the coordinates.
Reference: Output Parameters (Precise Defect)
(p.376)
Necessary Steps Optional Steps
Verify/Adjust results
▲
Region Setting (Precise Defect)
▲
Measurement Parameters (Precise Defect)
Start
Settings completed
Test measurement
▲
Mask Setting (Precise Defect)
▲
Judgement Condition (Precise Defect)
▲
Output Parameters (Precise Defect)
