Calibration Data ReferenceFH/FZ5 Processing Item Function Reference Manual
711
4
Support Inspection and Measurement
Key Points for Test Measurement and Adjustment (Calibration Data Reference)
The following content is displayed in the "Detail result" area as text.
Measurement Results for Which Output Is Possible (Calibration Data Reference)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Calibration Data Reference)
Setting item Description
Judge Judge
A Affine transformation parameter A
B Affine transformation parameter B
C Affine transformation parameter C
D Affine transformation parameter D
E Affine transformation parameter E
F Affine transformation parameter F
X magnification X magnification.
Y magnification Y magnification.
Origin X Origin X.
Origin Y Origin Y.
X axis angle X axis angle.
Y axis angle Y axis angle.
XY axis angle XY axis angle.
Setting item Character string Description
Judge JG Judge
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (insufficient memory)
-20: Error (other errors)
5 A Get only -
6 B Get only -
7 C Get only -
8 D Get only -
9 E Get only -
10 F Get only -
11 X magnification Get only -
12 Y magnification Get only -
13 Origin X Get only -
