Flexible SearchFH/FZ5 Processing Item Function Reference Manual
117
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Flexible Search)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Flexible Search)
Measurement items Character string Description
Judgement JG Judgement result
Model No. NO Model No. of the biggest correlation
Correlation value CR Correlation value with the model
Measurement coordinate X X X coordinate of the position where
the model is detected
Measurement coordinate Y Y Y coordinate of the position where
the model is detected
Measurement angle TH Angle of the position where the model is detected
Reference position X SX X coordinate of the reference position of the registered model
Reference position Y SY Y coordinate of the reference position of the registered model
Reference angle ST Angle of the registered model
Detection point RX RX X coordinate of the registered model
Detection point RY RY Y coordinate of the registered model
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Model No. Get only
0 to 4
-1: No models found
6 Correlation value Get only 0 to 100
7 Measure X Get only -99999.9999 to 99999.9999
8 Measure Y Get only -99999.9999 to 99999.9999
9 Measure angle Get only -180 to 180
10 Reference X Get only -99999.9999 to 99999.9999
11 Reference Y Get only -99999.9999 to 99999.9999
12 Reference angle Get only -180 to 180
13 Detection point X Get only -99999.9999 to 99999.9999
14 Detection point Y Get only -99999.9999 to 99999.9999
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Search mode Set/Get
0: Correlation
1: Shape
121 With rotation Set/Get
0: OFF
1: ON
122 Upper limit of the rotation angle Set/Get -180 to 180
123 Lower limit of the rotation angle Set/Get -180 to 180
