Sensitive SearchFH/FZ5 Processing Item Function Reference Manual
127
2
Inspecting and Measuring
Output Parameters (Sensitive Search)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Sensitive Search)
The following content is displayed in the "Detail result" area as text.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether
to output coordinate
values to external devices before or after the position deflection
correction is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration
in the values output to
the external device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall judgement
•[ON]
•OFF
Enables choosing whether or not th
e judg
ement results of this
processing unit is reflected in the scene overall judgment.
Display cursor setting
Position
•[ON]
•OFF
The measurement coordinate position of the de
tected model is
displayed at the cursor.
Sub-region
• Display
•[OFF]
The coordinate position of the region with the lowest correlation
value
of the sub-regions is displayed at the cursor.
• Executing test measurements will also update the meas
urement results and the figures in the image.
Displayed items Description
Judge Judgement result
Correlation Lowest correlation value in the sub-region
Position X X coordinate of the position where th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Angle θ Angle of the position where the model is detected
Deviation Highest density deviation in the sub-region
NG Sub-region NG region count
