Circular Scan Edge WidthFH/FZ5 Processing Item Function Reference Manual
289
2
Inspecting and Measuring
Output Parameters (Circular Scan Edge Width)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Circular Scan Edge Width)
The following contents can be displayed as text in the "Detail result" area.
The image specified in the Sub-image number in image display setting is displayed in the Image Display area.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Enables choosing whether or not the judgment results of this processing
unit is reflected in the scene overall judgment.
Displayed items Description
Judge Judgement result
Edge width Max. The maximum value of edge width
Edge width Min. The minimum value of edge width
Edge width Ave. The average value of all the edge width
Lost width count The number of the scanned areas for which the detectio
n of width failed
Sub image number. Explanation of image to be displayed
0 Measurement image
1 Scan region
Parameter to be adjusted Remedy
Measurement
If the color of the edges to be detected is decided, spe
cify the color with [Edge color]. If results
are not stable even with the color specified, specify a larger value for the color variance range.
If noise is detected as an edge, specify larger valu
es
for "Noise level" and "Noise width".
Important
