Glue Bead InspectionFH/FZ5 Processing Item Function Reference Manual
503
2
Inspecting and Measuring
Measurement Results for Which Output is Possible (Glue Bead Inspection)
Measurement items
Character
string
Description
Judge JG
1: OK
0: Unmeasured
-1: NG
State ST
Condition of measured result
0: Detectable
1: Gapped
2: Path error
-1: Unmeasured
-2: Region not yet registered
-3: Coating not yet detected
-4: Excessive path (insufficient memory)
Min. width MINWD Min. width
Max. width MAXWD Max. width
Average width AVGWD Average width
Gap width GAPWD Gap width
Coordinate X1 with the
m
i
nimum width
MINX1 X coordinate X 1 with the minimum width
Coordinate Y with the
m
i
nimum width
MINY1 Y Coordinate Y1 with the minimum width
Coordinate X2 with the
m
inimum width
MINX2 X coordinate X2 with the minimum width
Coordinate Y2 with the
m
inimum width
MINY2 Y coordinate Y2 with the minimum width
Coordinate X1 with the
m
a
ximum width
MAXX1 X coordinate X 1 with the maximum width
Coordinate Y1 with the
m
aximum width
MAXY1 Y coordinate Y1 with the maximum width
Coordinate X2 with the
m
aximum width
MAXX2 X coordinate X2 with the maximum width
Coordinate Y2 with the
m
a
ximum width
MAXY2 Y coordinate Y2 with the maximum width
Coordinate X1 of gap width GAPX1 X coordinate X1 of gap width
Coordinate Y1 of gap width GAPY1 Y coordinate Y1 of gap width
Coordinate X2 of gap width GAPX2 X coordinate X2 of gap width
Coordinate Y2 of gap width GAPY2 Y coordinate Y2 of gap width
