Search
104
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Search)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Search)
The following content is displayed in the "Detail result" area as text.
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whethe
r
to output coordinate values to
external devices before or after the position deflection correction is
applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration
i
n the values output to the
external device as measurement results.
ON: Output the coordinates converted
in
to actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
judgement
•[ON]
•OFF
Enables choosing whether or not the judgement results of this processing
unit is reflected in the scene overall judgment.
• Executing test measurements will also update the measurement results and the figures in the image.
Displayed item Description
Judge Judgement result
Count Count
Correlation value Correlation value
Measure X X coordinate of the position wh
ere th
e model is detected
Measure Y Y coordinate of the position where th
e model is detected
Angle θ Angle of the position where the model is detected
