2D CodeFH/FZ5 Processing Item Function Reference Manual
433
2
Inspecting and Measuring
External Reference Tables (2D Code)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
6 Decoded character count Get only Number of characters included in code detected
7 Decoded character string Get only Character string included in code detected
8 Index Get only
0 to 35
-1: Where there was no match with any of the index
comparison strings, or the inde
x comparison string has not
been set up.
9 Error code Get only
0: Completed successfully
-1: The 2D code cannot be found.
-3: Timeout
-7: Process could not be completed with too large a volume
of d
ata.
18 Cell recognition rate Get only
The rate is calculated based on the "the number of error
code word to be correctable", which is determined by the
size and the error correction level, and the number of error
code words that are actually corrected.
(1 - (number of error code wo
rd
s corrected) / (number of
error code words that can be corrected)) × 100
19 Contrast Get only 0 to 100
20 Focus Get only 0 to 100
21 Overall quality (Normal:DM) Get only 0 to 4
22 Decode (Normal:DM) Get only 0 to 4
23 Contrast Get only 0 to 4
24 Modulation Get only 0 to 4
25 Fixed pattern damage Get only 0 to 4
26 Axial nonuniformity Get only 0 to 4
27 Grid nonuniformity Get only 0 to 4
28 Unused error correction Get only 0 to 4
29 Print Scale Get only 0 to 4
30 Print Scale X Get only 0 to 4
31 Print Scale Y Get only 0 to 4
33
Overall quality (Normal:PDF417/
MicroPDF417)
Get only 0 to 4
34
Decode (Normal:PDF417/
Micro
PDF417)
Get only 0 to 4
35 RAP contrast Get only 0 to 4
36 RAP reflectance Get only 0 to 4
37 RAP edge contrast Get only 0 to 4
38 RAP modulation Get only 0 to 4
39 RAP defect Get only 0 to 4
40 RAP decodability Get only 0 to 4
41 RAP additional Get only 0 to 4
