Selective Branch
868
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Selective Branch)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error(image format mismatch)
-11: Error(unregistered model)
-12: Error(insufficient memory)
-20: Error(other errors)
5 Condition No. Get only -1 to 31
6 Branch place Get only -1 to 9,999
7 Conditional expression Get only -
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Miscompare branch place Set/Get -1 to 9,999
121 Miscompare judgement Set/Get
0: NG
1: OK
122 Condition value judge Set/Get Exp. character string
123 Timeout Set/Get
0: Not used
1: Used
124 Timeout time[s] Set/Get 1 to 3,600
130 + N × 10
(N = 0 to 31)
Destination unit No. N Set/Get
-1: Complete processing
0 to 9999: Unit No.
131+ N × 10
(N = 0 to 31)
Condition value N Set/Get -9,999 to 9,999
132 + N × 10(
N = 0 to
31)
Comment N Set/Get Character string
133 + N × 10
(N = 0 to 31)
Validation Flag N Set/Get
0: No validation
1: Validation
