Conveyor CalibrationFH/FZ5 Processing Item Function Reference Manual
829
4
Support Inspection and Measurement
Conveyor Calibration
Conveyor Calibration is an FH Sensor Controller processing item exclusively for conveyor tracking application.
Conveyor Calibration cannot be launched from an FH Sensor Controller User Interface. Use Sysmac Studio for
this function.
For more information, refer to: the V
ision Sensor FH Series Conveyor Tra
cking Application Sample Scene and
Sample Macro User's Guide
Used in the Following Case
Conveyor Calibration is used to calibrate camera, conveyor, and robots for conveyor tracking application.
• You can choose exclusive processing items for conveyor tracking application on the Edit Flow Window on the FH/FZ5
Sensor Controller. However, properties setting is unavailable on the FH/FZ5 Sensor Controller.
The following image is the Properties Setting window when it is opened on the FH/FZ5 Sensor Controller.
To Next Page
