Page #696 background imageLoading...
Page #696 background image
Focus
694
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Focus)
Specifies whether or not the judgement results of this processing unit is reflected in the scene overall judgement.
1 Click [Output parameter] in the Item Tab area.
2 Choose whether or not to reflect this in the scene overall judgement in "Reflect to overall
judgement" area.
Key Points for Test Measurement and Adjustment (Focus)
External Reference Tables (Focus)
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgement
• [ON]
•OFF
Enables choosing whether or not the judgment results of this
processing unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Focus Focus value
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
1
Measurement data Focus
value
Get only 0 to 255
2 Focus maximum value Get only 0 to 255
3 Last focus value Get only 0 to 255
103
Setting data Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
120
Setting data Focus value
Lower limit
Set/Get 0 to 255
