CalculationFH/FZ5 Processing Item Function Reference Manual
629
4
Support Inspection and Measurement
External Reference Tables (Calculation)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 to
12
Expression result of
Exp
r
ession 0 -
Expression result of
Expr
ess
ion 7
Set/Get -999999999.9999 to 999999999.9999
13 to
20
Judgement result of
Exp
ression 0 -
Judgement result of
Expr
ess
ion 7
Get only 0: Unmeasured, 1: OK, -1: NG
103
Reflect to overall
j
udgement
Set/Get 0: ON, 1: OFF
120 Upper limit 0 for judgement Set/Get -999999999.9999 to 999999999.9999
121 Lower limit 0 for judgement Set/Get -999999999.9999 to 999999999.9999
122 Upper limit 1 for judgement Set/Get -999999999.9999 to 999999999.9999
123 Lower limit 1 for judgement Set/Get -999999999.9999 to 999999999.9999
124 Upper limit 2 for judgement Set/Get -999999999.9999 to 999999999.9999
125 Lower limit 2 for judgement Set/Get -999999999.9999 to 999999999.9999
126 Upper limit 3 for judgement Set/Get -999999999.9999 to 999999999.9999
127 Lower limit 3 for judgement Set/Get -999999999.9999 to 999999999.9999
128 Upper limit 4 for judgement Set/Get -999999999.9999 to 999999999.9999
129 Lower limit 4 for judgement Set/Get -999999999.9999 to 999999999.9999
130 Upper limit 5 for judgement Set/Get -999999999.9999 to 999999999.9999
131 Lower limit 5 for judgement Set/Get -999999999.9999 to 999999999.9999
132 Upper limit 6 for judgement Set/Get -999999999.9999 to 999999999.9999
133 Lower limit 6 for judgement Set/Get -999999999.9999 to 999999999.9999
134 Upper limit 7 for judgement Set/Get -999999999.9999 to 999999999.9999
135 Lower limit 7 for judgement Set/Get -999999999.9999 to 999999999.9999
136 + N × 1
(N = 0 to 7)
Expressions comment Set/Get Character string
144 + N× 1
(N = 0 to 7)
Expressions Set/Get Exp. character string
160 + N × 1
(N = 0 to 7)
Comment view N Set/Get
0: OFF
1: ON
