Display Last NG Image
886
FH/FZ5 Processing Item Function Reference Manual
4 Set up the judgement condition.
Output Parameters (Display Last NG Image)
Specifies whether or not the judgement results of this processing unit is reflected in the scene overall judgement.
1 Click [Output parameter] in the Item Tab area.
2 Choose whether or not to reflect the judgement result in the scene overall judgement in
"Reflect to overall judgement" area.
Key Points for Test Measurement and Adjustment (Display Last NG Image)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is dis
played in the image display area.
• For stored data, refer to Measurement Results for Which Output Is Possible (Display Last NG Image) on p.887.
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgment results of this
processing unit is reflected in the scene overall judgment.
Displayed items Description
Data 0 comment Expression result of Expression 0
Data 1 comment Expression result of Expression 1
Data 2 comment Expression result of Expression 2
Data 3 comment Expression result of Expression 3
Data 4 comment Expression result of Expression 4
Data 5 comment Expression result of Expression 5
Data 6 comment Expression result of Expression 6
Data 7 comment Expression result of Expression 7
Data 8 comment Expression result of Expression 8
Data 9 comment Expression result of Expression 9
Data 10 comment Expression result of Expression 10
Data 11 comment Expression result of Expression 11
Data 12 comment Expression result of Expression 12
Data 13 comment Expression result of Expression 13
Data 14 comment Expression result of Expression 14
Data 15 comment Expression result of Expression 15
Sub image number. Explanation of image to be displayed
0 Last NG
1
Previous NG error image (Displayed when there are 2
or more saved images. Otherwise, "Last
NG" is displayed.)
2
NG error image from 2 previous (Displayed wh
en th
ere are 3 or more saved images.
Otherwise, "Last NG" is displayed.)
3
NG error image from 3 previous (Displayed wh
en there are 4 or more saved images.
Otherwise, "Last NG" is displayed.)
Note
