Position Data Calculation
716
FH/FZ5 Processing Item Function Reference Manual
Output Setting (Position Data Calculation)
Specifies whether or not the judgement results of this processing unit is reflected in the overall judgement.
1 Click [Output setting] in the Item Tab area.
2 Choose whether or not to reflect the judgement result in the scene overall judgement in
"Reflect to overall judgement" area.
Key Points for Test Measurement and Adjustment (Position Data Calculation)
The following content is displayed in the "Detail result" area as text.
Measurement Results for Which Output Is Possible (Position Data Calculation)
The following values can be output using processing items related to the "output result" proccessing item. It is
also possible to reference measurement values from expressions and other processing units.
Setting item
Setting value
[Factory default]
Description
Reflect to overall
judgement
•[ON]
•OFF
Specify whether or not the judgement results of this processing unit is
reflected in the scene overall judgement.
Setting item Description
Judge Judge
Calculation position X Calculation position X
Calculation position Y Calculation position Y
Calculation angle Calculation angle
Setting item
Character
string
Description
Judge JG Judge
Calculation position X X Calculation position X
Calculation position Y Y Calculation position Y
Calculation angle TH Calculation angle
Calculation angle (Point 0) TH0 Calculation angle for Point 0
Calculation angle (Point 1) TH1 Calculation angle for Point 1
Calculation angle (Point 2) TH2 Calculation angle for Point 2
Calculation angle (Point 3) TH3 Calculation angle for Point 3
Calculation angle (Point 0-1) TH01 Angle created by connecting Point 0-1.
Calculation angle (Point 0-2) TH02 Angle created by connecting Point 0-2.
Calculation angle (Point 0-3) TH03 Angle created by connecting Point 0-3.
Calculation angle (Point 1-0) TH10 Angle created by connecting Point 1-0.
Calculation angle (Point 1-2) TH12 Angle created by connecting Point 1-2.
Calculation angle (Point 1-3) TH13 Angle created by connecting Point 1-3.
Calculation angle (Point 2-0) TH20 Angle created by connecting Point 2-0.
Calculation angle (Point 2-1) TH21 Angle created by connecting Point 2-1.
Calculation angle (Point 2-3) TH23 Angle created by connecting Point 2-3.
Calculation angle (Point 3-0) TH30 Angle created by connecting Point 3-0.
