Machine SimulatorFH/FZ5 Processing Item Function Reference Manual
555
3
Compensate image
External Reference Tables (Machine Simulator)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
120 Reference scene No. Set/Get
-1: Current scene referred
0 to 9,999: Pointed scene referred
121 Reference unit No. Set/Get
-1: No reference
0 to 9,999: Pointed unit referred
122 Magnification Set/Get 0.0001 to 9.9999
123 Angle of X-axis Set/Get -180.0000 to 180.0000
124 Coordinate Set/Get
0: Lefthand
1: Righthand
125 Origin X (pix) Set/Get -99,999.9999 to 99,999.9999
126 Origin Y (pix) Set/Get -99,999.9999 to 99,999.9999
127 Source image Set/Get
0: Camera image
1: Previous image
128 X-axis movement Set/Get -99,999.9999 to 99,999.9999
129 Y-axis movement Set/Get -99,999.9999 to 99,999.9999
130 θ-axis movem
e
nt Set/Get -360.0000 to 360.0000
131 θ-axis (linear drive) Set
/Get -99,999.9999 to 99,999.9999
132 U-axis movement Set/Get -99,999.9999 to 99,999.9999
133 V-axis movement Set/Get -99,999.9999 to 99,999.9999
134 W-axis movement Set/Get -99,999.9999 to 99,999.9999
135 R-axis movement Set/Get -99,999.9999 to 99,999.9999
136 Current X-axis movement Set/Get -99,999.9999 to 99,999.9999
137 Current Y-axis movement Set/Get -99,999.9999 to 99,999.9999
138 Current θ-axis movement Set
/Get -180.0000 to 180.0000
139 Current θ-axis (l
inear drive) Set/Get -99,999.9999 to 99,999.9999
140 Current U-axis movement Set/Get -99,999.9999 to 99,999.9999
141 Current V-axis movement Set/Get -99,999.9999 to 99,999.9999
142 Current W-axis movement Set/Get -99,999.9999 to 99,999.9999
143 Current R-axis movement Set/Get -99,999.9999 to 99,999.9999
144 Origin X (Actual) Set/Get -99,999.9999 to 99,999.9999
145 Origin Y (Actual) Set/Get -99,999.9999 to 99,999.9999
146 Setting method of origin Set/Get
0: Pixel
1: Actual
