Omron fh-3 series User Manual

ECM SearchFH/FZ5 Processing Item Function Reference Manual
143
2
Inspecting and Measuring
External Reference Tables (ECM Search)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Correlation value Get only 0 to 100
6 Measure X Get only -99999.9999 to 99999.9999
7 Measure Y Get only -99999.9999 to 99999.9999
8 Angle θ Get only -180 to 180
9 Magnification X Get only 50 to 150
10 Magnification Y Get only 50 to 150
11 Reference X
*1
Get only -99999.9999 to 9999.9999
12 Reference Y
*1
Get only -99999.9999 to 9999.9999
13 Reference angle Get only -180 to 180
14 Detection point X Get only -99999.9999 to 9999.9999
15 Detection point Y Get only -99999.9999 to 9999.9999
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
j
udgement
Set/Get
0: ON
1: OFF
120 Mask size Set/Get
0: 3 × 3
1: 5 × 5
2: 7 × 7
3: 9 × 9
121 Edge Level Set/Get 0 to 255
122 Detection point X
*2
Set/Get 0 to 99999.9999
123 Detection point Y
*2
Set/Get 0 to 99999.9999
124 Reference X Set/Get 0 to 99999.9999
125 Reference Y Set/Get 0 to 99999.9999
126 Upper limit of the corr. Set/Get 0 to 100
127 Lower limit of the corr. Set/Get 0 to 100
128 Upper limit of measure X Set/Get -99999.9999 to 99999.9999
129 Lower limit of measure X Set/Get -99999.9999 to 99999.9999
130 Upper limit of measure Y Set/Get -99999.9999 to 99999.9999
131 Lower limit of measure Y Set/Get -99999.9999 to 99999.9999
132 Upper limit of the angle Set/Get -180 to 180
133 Lower limit of the angle Set/Get
-180 to 180
134 Candidate Point Level Set/Get 0 to 99
135 Model skipping Set/Get 1 to 9
136 Region skipping Set/Get 1 to 19
137 Reduction Set/Get 10 to 100
