144
FH/FZ5 Processing Item Function Reference Manual
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
138 With rotation Set/Get
0:No rotation
1: With rotation
139
Lower limit of the rotation
a
ngle
Set/Get -180 to 180
140
Upper limit of the rotation
a
ngle
Set/Get -180 to 180
141 Skipping angle Set/Get 1 to 30
142 Move axis Set/Get
0: No size change
1: XY change
2: X change
3: Y change
143
Upper limit of the size
ch
ange
Set/Get 50 to 150
144
Lower limit of the size
ch
ange
Set/Get 50 to 150
145 Size change skipping Set/Get 1 to 99
146 Reverse Set/Get
0: No reverse
1: Reverse
No. Data name Set/Get Data range
