Circular Scan Edge PositionFH/FZ5 Processing Item Function Reference Manual
279
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Circular Scan Edge Position)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Circular Scan Edge Position)
Measurement items Character string Description
Judgement JG
1: OK
0: Not yet measured
-1: NG
Center coordinate X X The center X coordinate of the calculation result
Center coordinate Y Y The center Y coordinate of the calculation result
Radius R The radius of the calculation result
Maximum radius MAXR The maximum radius of the calculation result
Minimum radius MINR The minimum radius of the calculation result
Decentration X DEX The decentration X of the calculation result
Decentration Y DEY The decentration Y of the calculation result
Number of lost points LOST Number of parts for which the detection of edges has failed
Reference coordinate X SX X coordinate of the reference coordinates
Reference coordinate Y SY Y coordinate of the reference coordinates
Maximum radius region
number
MAXNO The region number for the maximum radius
Minimum radius region
number
MINNO The region number for the minimum radius
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Central X Get only -99,999.9999 to 99,999.9999
6 Central Y Get only -99,999.9999 to 99,999.9999
7 Radius Get only 0 to 99,999.9999
8 Max. radius Get only 0 to 99,999.9999
9 Min. radius Get only 0 to 99,999.9999
10 Deviation X Get only -99,999.9999 to 99,999.9999
11 Deviation Y Get only -99,999.9999 to 99,999.9999
12 Lost point Get only 0 to 360
13 Reference X
*1
Get only 0 to 99,999.9999
14 Reference Y
*1
Get only 0 to 99,999.9999
15 Max. radius region No. Get only 0 to 359
16 Min. radius region No. Get only 0 to 359
17 Approx. radius Get only 0 to 99,999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
