Calc Axis Move by Multipoint
808
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Calc Axis Move by Multipoint)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement(unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 X-axis movement Get only -
6 Y-axis movement Get only -
7 θ-axis movement Get only -180.0000 to 180.0000
8 θ-axis(linear drive) Ge
t only -
9 U-axis movement Get only -
10 V-axis movement Get only -
11 W-axis movement Get only -
12 R-axis movement Get only -
13 Position X difference Get only -
14 Position Y difference Get only -
15 Angle difference Get only -
16 Error max. Get only -
17 Error min. Get only -
18 Error ave. Get only -
19 The number of removal points Get only -
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Reference scene No. Set/Get
-1: Current scene refered
0 to 9999:Pointed scene refered
121 Reference unit No. Set/Get
-1: No reference
0 to 9999:Pointed unit refered
122 Measure type Set/Get
0: Side measure
1: Points alignment
123 Expressions of reference angle Set/Get Exp. character string
124
Expressions of measurement
ang
le
Set/Get Exp. character string
125 Measure axis Set/Get 0 to 1
126 Setting type Set/Get 0 to 1
127 Point 0 Set/Get -1 to 7
128 Point 1 Set/Get -1 to 7
129 Side alignment's point number Set/Get 3 to 8
130 Reauired points number for calc. Set/Get 2 to 8
131
The number of min. necessary
poin
ts
Set/Get 2 to 8
132 Error tolerance Set/Get 0 to 9,9999.9999
133 Upper limit of error Set/Get 0 to 9,9999.9999
134 Matching method Set/Get
0: Least square method
1: Maximum error minimization
150 Current X-axis movement Set/Get Exp. character string
