FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (EC Circle Search)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Position X Get only -99999.9999 to 99999.9999
6 Position Y Get only -99999.9999 to 99999.9999
8 Reference coordinate X
*1
Get only -99999.9999 to 99999.9999
9 Reference coordinate Y
*1
Get only -99999.9999 to 99999.9999
15 Evaluation Get only 0 to 100
18 Radius Get only 0 to 99999.9999
19 Count Get only 0 to 256
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
judg
ement
Set/Get
0: ON
1: OFF
140 Reference X
*2
Set/Get -99999.9999 to 99999.9999
141 Reference Y
*2
Set/Get -99999.9999 to 99999.9999
142 Target Set/Get
0: Black
1 : White
2: Black and white
143 Edge color specification Set/Get
0: Yes
1: No
144 Circle color R Set/Get 0 to 255
145 Circle color G Set/Get 0 to 255
146 Circle color B Set/Get 0 to 255
147 Background color R Set/Get 0 to 255
148 Background color G Set/Get 0 to 255
149 Background color B Set/Get 0 to 255
150 Mask size Set/Get
0: 3 × 3
1: 5 × 5
2: 7 × 7
3: 9 × 9
151 Edge level Set/Get 0 to 255
153 Upper limit of position X Set/Get -99999.9999 to 99999.9999
154 Lower limit of position X Set/Get -99999.9999 to 99999.9999
155 Upper limit of position Y Set/Get -99999.9999 to 99999.9999
156 Lower limit of position Y Set/Get -99999.9999 to 99999.9999
159 Upper limit of evaluation Set/Get 0 to 100
160 Lower limit of evaluation
Set/Get 0 to 100
