Scan Edge Width
266
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Scan Edge Width)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
1 Edge width Max. Get only 0 to 99999.9999
2 Edge width Min. Get only 0 to 99999.9999
3 Edge width Ave. Get only 0 to 99999.9999
4 Lost width count Get only 0 to 100
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Edge color specification Set/Get
0: OFF
1: ON
121 Edge color R Set/Get 0 to 255
122 Edge color G Set/Get 0 to 255
123 Edge color B Set/Get 0 to 255
124 Difference R Set/Get 0 to 127
125 Difference G Set/Get 0 to 127
126 Difference B Set/Get 0 to 127
127 Detection mode Set/Get
0: Color IN
1: Color OUT
129 Edge level lower limit Set/Get 0 to 100
130 Noise level Set/Get
Color camera:0 to 442
Monochrome camera: 0 to 255
131 Noise width Set/Get 0 to 9999
132 Edge color level Set/Get 0 to 442
133 Upper limit of the Max. width Set/Get 0 to 99999.9999
134 Lower limit of the Max. width Set/Get 0 to 99999.9999
135 Upper limit of the Min.width Set/Get 0 to 99999.9999
136 Lower limit of the Min.width Set/Get 0 to 99999.9999
137
Upper limit of the average
wi
d
th
Set/Get 0 to 99999.9999
138
Lower limit of the average
wi
dth
Set/Get 0 to 99999.9999
139
Upper limit of the lost width
co
unt
Set/Get 0 to 100
140
Lower limit of the lost width
co
unt
Set
/Get 0 to 100
