Shape Search IIFH/FZ5 Processing Item Function Reference Manual
157
2
Inspecting and Measuring
Settings Flow (Shape Search II)
Set up shape search II according to the following steps.
List of Shape Search II Items
Item name Description
Model
This item registers the pattern charac
teristic of the measurement image as a model.
Change the model parameter (black and white reverse) as necessary
.
Reference: Model Registration (Shape Search II) (p.158)
Region setting
This item is used to set up the measurement area.
Instead of measuring the entire input image, narrowin
g the measurement area shortens the processing
time.
Reference: Region Setting (Shape Search II) (p.159)
Detection point
This item can be changed if necessary. Specify a posit
ion in the model that should be used as the
detection coordinates during measurement. Usually, the central position of the set model is registered as
the detection coordinates.
Reference: Detection Point (Shape Search II) (p.160)
Ref. setting
This item can be changed if necessary. Specify the reference
position within the camera's field of view.
Reference: Reference Setting (Shape Search II) (p.161)
Measurement
This item specifies the judgement condition for measur
ement results. Specify the criteria to judge the
measurement result if the X and Y coordinates and the correlation values with the model are OK.
Reference: Measurement Parameters (Shape Search II) (p.162)
Output
p
a
rameter
This item can be changed if necessary. Normally
, the factory default value will be used.
Use the output parameter to specify how to handle th
e coordinates.
Reference: Output Parameters (Shape Search II) (p.164)
Necessary Steps Optional Steps
Verify/Adjust results
Model Registration (shape search II)
Region Setting (shape search II)
Measurement Parameters (shape search II)
Detection Point (shape search II)
Reference Setting (shape search II)
Output Parameters (shape search II)
Start
Settings completed
Test measurement
