Model Dictionary
416
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Model Dictionary)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When the processing speed is slow
Measurement Results for Which Output Is Possible (Model Dictionary)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Model Dictionary)
Displayed items Description
Judge Judgement result
Parameter to be adjusted Remedy
Model
If the model image consists of detailed figures, specify a
larger
value for "Stab.".
When "Rotation" is selected, if the model shape is co
mplex, uncheck the "Smart mode" option.
Measurement If images that should be judged OK vary greatly, specify a smaller value for "Candidate level".
Parameter to be adjusted Remedy
Model
If the model image is a simple figure or a large figure,
specify a smaller value for "Stab." If
lowering stability does not speed up processing, it is likely that many candidates have been
detected. Raise the "Candidate level" in [Measurement].
When "Rotation" is selected, if the model shape is si
mple, place a check at the "Smart mode"
option.
Measurement If images that should be judged OK vary little, specify a larger value for "Candidate level".
Measurement items Character string Description
Judgement JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
121 With rotation Set/Get
0: OFF
1: ON
122
Upper limit of the rotation
a
ngl
e
Set/Get -45 to 45
123
Lower limit of the rotation
a
ngl
e
Set/Get -45 to 45
125 Smart mode Set/Get
0: OFF
1: ON
126 Stab. Set/Get 1 to 15
127 Prec. Set/Get 1 to 3
To Next Page
