ECM SearchFH/FZ5 Processing Item Function Reference Manual
141
2
Inspecting and Measuring
[Note 1]: When the ECM correlation value of the measurement result is 0, the judgement result will be NG regardless of the
measurement parameters setting.
Output Parameters (ECM search)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (ECM Search)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is dis
played in the image display area.
Setting item Set value Description
Measure pos X -99999.9999 to 99999.9999
Specify the range of X-axis shifting that is judged to be
OK.
Measure pos Y -99999.9999 to 99999.9999
Specify the range of Y-axis shifting that is judged to be
OK.
Measure angle -180 to 180 Specify the range of angles that are judged to be OK.
Correlation [Note 1] 0 to 100
Specify the range of correlation
val
ues that are judged to
be OK.
• After setting up the measurement parameters, changing the output p
a
rameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordi
nate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration
in
the values output to the
external device as measurement results.
ON: Output the coordinates converted in
to
actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
judgement
•[ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgment.
Displayed item Description
Judge Judgement result
Correlation Correlation value
Position X X coordinate of the position where th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Angle θ Angle of the position where the model is detected
Sub image number. Explanation of image to be displayed
0 Measurement image
1
Measurement image displayed with matchi
ng models overlaid
Green: Matched model points
Red: Unmatched model points
Important
