Trend Monitor
672
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Trend Monitor)
• If the total measurement value data exceeds -1.0 × 10^11 to 1.0 × 10^11, the measurement will be disabled (NG).
Regularly clear the measurement values so that the
total measurement value data stays within the range.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Measurement Get only -999999999.9999 to 999999999.9999
6 Warning Get only
0: OFF
1: ON
7 Maximum Get only -999999999.9999 to 999999999.9999
8 Minimum Get only -999999999.9999 to 999999999.9999
9 Average Get only -999999999.9999 to 999999999.9999
10 Deviation Get only -999999999.9999 to 999999999.9999
11 Count Get only 0 to 999999999
12 NG count Get only 0 to 999999999
13 Warning count Get only 0 to 999999999
14
Measurement value
av
erage plus 3σ
Get only -999999999.9999 to 999999999.9999
15
Measurement value
a
v
erage plus σ
Get only -999999999.9999 to 999999999.9999
16
Measurement value
a
verage minus σ
Get only -999999999.9999 to 999999999.9999
17
Measurement value
a
verage minus 3σ
Get only -999999999.9999 to 999999999.9999
18 OK count Get only 0 to 999999999
19 Yield Get only 0 to 1
103
Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
121
Upper limit of the
j
udg
ement
Set/Get -999999999.9999 to 999999999.9999
122
Lower limit of the
j
udgement
Set/Get -999999999.9999 to 999999999.9999
123 Warning upper limit Set/Get -999999999.9999 to 999999999.9999
124 Warning lower limit Set/Get -999999999.9999 to 999999999.9999
125
Upper limit of the display
ra
nge
Set/Get -999999999.9999 to 999999999.9999
126
Lower limit of the display
ra
nge
Set/G
et -999999999.9999 to 999999999.9999
127
Amount of change to
display range
Set/Get 1 to 1000000
128 Horizontal Set/Get
0: Display 200 results
1: Display 1000 results
