FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Search)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Measurement items Character string Description
Judgement result JG Judgement result
Count C
Number of search items detected
If none detected, 0
Correlation value CR Correlation value with the model
Measurement coordinate X X X coordinate of the position where the model is detected
Measurement coordinate Y Y Y coordinate of the position where the model is detected
Measurement angle TH Angle of the position where the model is detected
Reference position X SX X coordinate of the reference position of the registered model
Reference position Y SY Y coordinate of the reference position of the registered model
Reference angle ST Angle of the registered model
Detection point RX RX X coordinate of the registered model
Detection point RY RY Y coordinate of the registered model
Correlation value N (N = 00 to
127)
CRN Detected search N correlation value (N = 00 to 127)
Position N (N = 00 to 127) XN Detected search N position X (N = 00 to 127)
Position N (N = 00 to 127) YN Detected search N position Y (N = 00 to 127)
Angle N (N = 00 to 127) THN Detected search N angle TH (N = 00 to 127)
