Barcode
442
FH/FZ5 Processing Item Function Reference Manual
Results Settings (Barcode)
Results can be classified according to the judgement results.
1 In the Item Tab area, click [Result setting].
2 Register the character string that will be the reference for classification.
3 If necessary, set the quality display for
the "Detail result" display area.
Output Parameters (Barcode)
Select how measurement results are output to an external device. This item can be changed if necessary.
Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Setting item Set value Description
Classification string - Set the Verification
string. Up to 1023 characters can be set.
'*' '?' is treated as
character data.
• Checked
• [Unchecked]
Checked: '*' and '?' are handled as normal characters.
Unchecked: '*' and '?' are handled as special characters.
'*': Substitution for character string (with 0 or more characters)
'?': Substitution for 1character
Setting item Set value Description
Code quality display
• Checked
• [Unchecked]
Select whether or not to display integrated quality.
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgement
• [ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgement.
Character output
• Checked
• [Unchecked]
Set whether to output character strings.
Error output
• Checked
• [Unchecked]
Set whether to output errors.
Error output character
str
i
ng
---
Input the character string output
when there is an error.
Up to 20 characters can be input.
Output device
• [RS-232C/RS-
422]
•
Ethernet
When "Character output" is checked (character strin
g
s are output),
specify the device to which character strings are output. A character
string is output as an ASCII code character string plus a delimiter.
When Ethernet is selected, the destinatio
n IP address is determined
by the system settings.
Reference:  Non-pro
cedure Communications in the Vision System
FH
/FZ5 Series User’s Manual for Communications Settings (Cat. No.
Z342).
