Get Unit FigureFH/FZ5 Processing Item Function Reference Manual
659
4
Support Inspection and Measurement
Measurement Results for Which Output Is Possible (Get Unit Figure)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Measurement items Character string Description
Judge JG The latest processing unit judgement result
Number of figures NUM Number of figures acquired
Size of figures SIZ Size of figures acquired (number of bytes)
Figure N type
(N = 0 to 9)
FNT
Type of figure N
0x0000Un
define
d
0x0001Point
0x0002Li
ne
0x00
04Wide li
ne
0x0008Rect
angle
0x0010Ellipse
0x00
20Circl
e
0x0040Wi
de circle
0x0080Arc
0x0100W
ide arc
0x02
00Polygon
Set
to 0 if no figures are acquired.
Figure N mode
(N = 0 to 9)
FNM
Figure N drawing mode
0: OR 1: NOT
Set to 0 if no figures are acquired.
Figure N data 00 to 20
(N = 0 to 9)
FND 00 to FND 20
Data 0 to 20 of figure N
•For points
0: X coordinate
1: Y coordinate
For lines
0: X coordinate for first point
1: Y coordinate for first point
2: X coordinate for second point
3: Y coordinate for second point
For wide lines
0: X coordinate for first point
1: Y coordinate for first point
2: X coordinate for second point
3: Y coordinate for second point
4: Width
For rectangles
0: X coordinate for upper left point
1: Y coordinate for upper left point
2: X coordinate for lower right point
3: Y coordinate for lower right point
