Set Unit Figure
656
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Set Unit Figure)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following point.
Judgement will be NG.
Displayed items Description
Judge Judgment result
Setting target data 0 Judgment result
Setting target data 1 Judgment result
Setting target data 2 Judgment result
Setting target data 3 Judgment result
Setting target data 4 Judgment result
Setting target data 5 Judgment result
Setting target data 6 Judgment result
Parameter to be adjusted Troubleshooting
Setting parameters for
figures
• Check if the values entered for the setting figure are correct.
If the setting figure is a rectangle, check that coordi
nates are specified in the order from top-left
(X, Y) to bottom-right (X, Y). To refer to the measurement coordinates X and Y from other units,
the set order may be the top-right coordinates (X, Y) to bottom-left coordinates (X, Y).
If the setting figure is a circle, check that no n
ega
tive value is specified as the radius.
• Check that anything other than images are not included in the set figure.
• Check that figure size limit of the
setting
target is not exceeded.
