Omron fh-3 series User Manual

Trend Monitor
670
FH/FZ5 Processing Item Function Reference Manual
Extended format
3 In the "Save setting" area, click [Save].
Data is saved to a USB memory stick or SD Memory Card.
Output Parameters (Trend Monitor)
Specifies whether or not the judgement results of this processing unit is reflected in the scene overall judgement.
1 Click [Output parameter] in the Item Tab area.
2 Choose whether or not to reflect this in the scene overall judgement in "Reflect to overall
judgement" area.
Key Points for Test Measurement and Adjustment (Trend Monitor)
The following content can be confirmed in the "Detail result" area using text.
Line Text Description
1
<Maximum>, <Minimum>, <Deviation>, <Plus 3σ>,
<Plus σ>, <Average>, <Minus σ>, <Minus 3σ>, <Count>,
<OK count>, <NG count>, <Warni
ng count>, <Yield>
Statistical data
2
3
0, <judgement result, latest>, <measured value, latest>,
<Time>
Last
Measurement result
(Max: 100000
items)
4
1, <Last 1 judgement result>, <Last 1 Measurement>,
<T
ime>
Last 1
5
2, <Last 2 judgement result>, <Last 2 Measurement>,
<T
i
me>
Last 2
: : :
100002
99999, <Last 99999 judgement result>,
<Last 99999 Measurement>, <Time>
Last 99999
• The default for the file name is the data save date (example:
0410.csv). If it is half-width alphanumeric characters,
it can be changed arbitrarily.
Setting item
Set value
[Factory default]
Description
Reflect to overall
judgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgment results of this
processing unit is reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Measurement Latest measured value
Max Max. measurement value during recording period
Mini Min. measurement value during recording period
Standard deviation Standard deviation for measurement values during recording period
Plus 3σ
Average of measurement values during period recorded
+ standard deviation of the
measurement values × 3
Plus σ
Average of measurement values during period re
corded
+ standard deviation of the
measurement values
Average Average value for measurement values during recording period
Note
