Display Image File
882
FH/FZ5 Processing Item Function Reference Manual
3 Select the image to be displayed on the
Properties Dialogue Box.
4 Click [OK].
The settings are finalized.
Key Points for Test Measurement and Adjustment (Display Image File)
The following content can be confirmed in the "Detail result" area using text.
The image specified in the Sub-image number in image display setting is dis
played in the image display area.
External Reference Tables (Display Image File)
• The images in image file 0 to 3 can be displayed by specifying the sub image number on the RUN window/ ADJUST
window.
Reference: "Chapter 3 Performing Test Measurement/Starting Op
eration
Arranging the Window Changing Display
Contents, such as Image Mode" in the "Vision System FH/FZ5 Series User's Manual (Z365)"
Displayed item Description
Judge Judgement result
Sub image number. Explanation of image to be displayed
0 Image 0
1 Image 1
2 Image 2
3 Image 3
No. Data name Set/Get Data range
120 Number of files Set/Get 1 to 4
121 Camera No. [0] Set/Get 0 to 3
122 Camera No. [1] Set/Get 0 to 3
123 Camera No. [2] Set/Get 0 to 3
124 Camera No. [3] Set/Get 0 to 3
125 File name [0] Set/Get Character string
126 File name [1] Set/Get Character string
127 File name [2] Set/Get Character string
128 File name [3] Set/Get Character string
129 Capture No. [0] Set/Get 0 to 9999 (maximum depend on image file)
130 Capture No. [1] Set/Get 0 to 9999 (maximum depend on image file)
131 Capture No. [2] Set/Get 0 to 9999 (maximum depend on image file)
132 Capture No. [3] Set/Get 0 to 9999 (maximum depend on image file)
