Advanced Filter
604
FH/FZ5 Processing Item Function Reference Manual
Items Displayed in the Detail Result Area
The following measurement results are displayed in the “Detail result” area as text.
Items Displayed in the Image Display Area
You can specify a sub-image number to display the next image in the image display area.
Output of measurement results
There are no measurement results that can be output.
Key Points for Test Measurement and Adjustment (Advanced Filter)
You can adjust the parameters while you perform test measurements and check the measurement results to
increase the measurement precision and speed.
Select the adjustment method by considering the following point.
Check the measurement results that can be displayed and
outp
ut in “Measurement Results for Which Output is
Possible”.
(Reference: Measurement Results for Which Output Is Possible (Advanced Filter) (p.603))
Adjusting the Processing Speed of Measurements
You can use the following methods to improve the measurement processing speed.
When the processing speed is slow
Displayed item Description
Judge Displays the judgement result for the processing unit.
Sub image number Description
0 The advanced filter image appears.
1 The image of output image 0 appears.
2 The image of output image 1 appears.
3 The image of output image 2 appears.
4 The image of output image 3 appears.
5 The measurement image appears.
• When you perform test measurement, the display of the deta
ils and image are updated according to the measurement
results.
Parameter to be
adjusted
Description
Region setting
(Reference: Region
Settings (Advanced Filter)
(p.602))
If the measurement region is large, excessi
v
e time may be required for measurement
processing. Set as small a measurement region as possible.
