Camera Image Input HDR Lite
80
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Camera Image Input HDR Lite)
To set Camera Image Input HDR Lite, follow the steps below.
Camera Image Input HDR Lite Item List
Item name Description
Camera settings
Specify the camera settings such as the electronic flash.
Reference: Camera Settings (Camera Image Input HDR Lite) (p.81)
HDR setting
Specify the dynamic range and brightness setting. S
peci
fy the HDR automatic setting as necessary.
Reference: HDR settings (Camera Image Input HDR Lite) (p.81)
Screen adjust
Adjust the image with or witho
ut the light adjustment or using display line bright.
Reference: Screen adjust (Camera Image Input HDR Lite) (p.82)
White balance
When using a color camera, adjust the white balance.
The setting method is the same as for [Camera Image Input]. Please check it.
Reference: White Balance (Camera Image Input) (p.38)
Calibration
Set when measurements (camera coordinate measurement values) are to be output using actual
dimensions. Select the calibration setting method and generate the calibration parameters.
The setting method is the same as for [Camera Image Input]. Please check it.
Reference: Calibration (Camera Image Input) (p.39)
Be sure to perform settings
Start
Settings complete
Results confirmation/adjustment
▲
Camera Settings (Camera Image Input HDR Lite)
▲
HDR Settings (Camera Image Input HDR Lite)
▲
Screen adjust (Camera Image Input HDR Lite)
▲
White Balance (Camera Image Input)
▲
Calibration (Camera Image Input)
Test measurement
