Barcode
438
FH/FZ5 Processing Item Function Reference Manual
List of Barcode Items
Region Setting (Barcode)
Specify the rectangular area in which to search for the barcodes.
Restricting the measurement area can shorten the processing time.
1 In the Item Tab area, click [Region setting].
2 Click [Edit].
The figure setting area is displayed.
3 Specify the area in which to search for the barcodes.
The rectangle covering the entire screen is set. Adjust the size and position of the rectangle.
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
Item name Description
Region setting
This item is used to set up the measurement area.
Restricting the measurement area can sh
orten the processing time.
Reference: Region Setting (Barcode) (p.438)
Measurement
This item specifies the judgement condition for measurement results. Set the code type and the number of
characters to be judged as OK.
Reference: Measurement Parameters (Barcodes) (p.439)
Result setting
Set the measurement results. Judgement results can be classified.
Reference: Results Settings (Barcode) (p.442)
Output
p
arameter
This item can be changed if necessary. Normally, the factory default value will be used.
Reference: Output Parameters (Barcode) (p.442)
• Set the measurement region to be 2448 × 2044, or less.
• Set the measurement region such that
i
t contains only 1 barcode.
If there is more than one bar code in the measurement re
gion, measurement may not be performed correctly.
• Set the measurement region such that
it includes a quiet zone.
To Next Page
