Shape Search II
164
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (Shape Search II)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Shape Search II)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is displayed in the Image Display area.
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
Select output coordinate for external devices. If "af
ter scroll" is chose here
shape search III outputs coordinates after position compensation.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Enables choosing whether or not the judgement results of this processing
unit is reflected in the scene overall judgment.
• Executing test measurements will update the measurement results and the figures in the image.
Displayed items Description
Judge Judgement result
Count Number of detections
Correlation Correlation value
Position X X coordinate of the position wh
ere th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Angle Angle of the position where the model is detected
Sub image number. Explanation of image to be displayed
0 Measurement image
