PLC Master Calibration
768
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (PLC Master Calibration)
Set the PLC master calibration with the following steps.
List of PLC Master Calibration Items
Item name Description
Machine setting
Select a processing item (stage data or robot data) under
which external device information needed for
calculation of axis movement amount is held.
Reference: Machine Setting (PLC Master Calibration) (p.769)
Calibration
This item sets data related to calibration. Sets the numbe
r of calibration data to be created and the
measurement processing items to be used for sampling in the arithmetic expression.
Reference: Calibration (PLC Master Calibration) (p.769)
Sampling setting
This item sets data related to sampling.
Set the number of samplings and the actual coordinate posi
tions for each sampling.
Reference: Sampling Setting (PLC Master Calibration) (p.771)
Calibration result
The created calibration data is displayed in this item. The calibration data can be adjusted directly
using the Edit function.
It is also possible to confirm the sampling data used for the calculation.
Reference: Calibration Result (PLC Master Calibration) (p.772)
Make sure to set Set as necessary.
Check results/make adjustments
Start
▲
Calibration
(PLC Master Calibration)
▲
Sampling Setting
(PLC Master Calibration)
Settings complete
Test measurement
▲
Calibration result
(PLC Master Calibration)
▲
Machine setting
(PLC Master Calibration)
To Next Page
