Selective BranchFH/FZ5 Processing Item Function Reference Manual
867
5
Branch
Key Points for Adjustment (Selective Branch)
Select the adjustment method referring to the following points.
When the system freezes after executing the measurement
When measurement processing of an unintended unit is executed
When the judgement results (JG) of the unit within the flow is updated or not updated
Measurement Results for Which Output Is Possible (Selective Branch)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
• Normally the “Use timeout” check box should be selected. Unchecking the [Use timeout] checkbox may cause the
measurement flow to become stuck in an infinite loop when measurements are started depending on the
selective branching settings.
• If using selective branching within the block for the parallelization
task in the measurement flow, set it up so that
branching occurs only within the relevant block for the parallelization task. Attempting to introduce conditional
branching across blocks for the parallelization task may cause the timout function to stop working even with the
[Use timeout] checkbox checked.
Parameter to be adjusted Troubleshooting
Selection branch
An infinite loop occurs when the branch destination
unit is incorrect. In order to avoid a
measurement processing looping, for the branch destination, set a processing unit number that
is after the [Selection branch].
Parameter to be adjusted Troubleshooting
-
If [End] is not registered at the end of a branch, the processing
in the scene will continue to
move to the next unit No. even if the branch has been completed. Make sure to set "End" at the
last branch destination.
Parameter to be adjusted Troubleshooting
-
The system is designed this way.
For results other than the unit's judgement results (JG), the measurement result during the
previous pass is retained. The JG for units that do not pass through the condition branch
becomes unmeasured (0). Note, however, that the unit JG becomes unmeasured at the point in
time when all the measurement processing ends. During flow processing, the previous time
judgement (JG) is retained.
Measurement items
Character
string
Description
Judge JG Judgement result
Condition No JN Condition number that matches the sele
ction condition expression result
Destination BU
Branch destination unit number of the co
ndi
tion that matches the selection
condition expression result
Conditional expression DJ Expression result of the selecti
on cond
itional expression
Important
