Flexible SearchFH/FZ5 Processing Item Function Reference Manual
115
2
Inspecting and Measuring
Output Parameters (Flexible Search)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Flexible Search)
The following content is displayed in the "Detail result" area as text.
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordi
nate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration
in
the values output to the
external device as measurement results.
ON: Output the coordinates converted in
to
actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgment.
Displayed items Description
Judge Judgement result
Model number Model No. of the biggest correlation
Correlation Correlation value
Position X X coordinate of the position wh
ere th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Angle θ Angle of the position where the model is detected
• If the model is an ellipse, its circumscribing rectangle is displa
yed as the search result of the model.
Important
Note
