Shape Search II
166
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Shape Search II)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Correlation value Get only 0 to 100
6 Measurement coordinate X Get only -99999.9999 to 99999.9999
7 Measurement coordinate Y Get only -99999.9999 to 99999.9999
8 Measurement angle Get only -180 to 180
9 Reference coordinate X
*1
Get only -99999.9999 to 99999.9999
10 Reference coordinate Y
*1
Get only -99999.9999 to 99999.9999
11 Reference angle Get only -180 to 180
12 Detection coordinate X Get only -99999.9999 to 99999.9999
13 Detection coordinate Y Get only -99999.9999 to 99999.9999
14 Number of detections Get only 0 to 32
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 With rotation Set/Get
0: OFF
1: ON
121
Upper limit value of the
rot
a
tion angle
Set/Get -180 to 180
122
Lower limit value of the
rot
a
tion angle
Set/Get -180 to 180
124 Reverse Set/Get
0: Do not allow black and white reverse
1: Allow black and white reverse
126 High-Prec. Set/Get
0: OFF
1: ON
127 Reference coordinate X
*2
Set/Get 0 to 99999.9999
128 Reference coordinate Y
*2
Set/Get 0 to 99999.9999
133 Candidate point level Set/Get 0 to 100
134 Detection point X Set/Get 0.0000 to 9999.0000
135 Detection point Y Set/Get 0.0000 to 9999.0000
136 Sort condition Set/Get
0: Correlation value ascending
1: Correlation value descending
2: Measurement coordinate X ascending
3: Measurement coordinate X descending
4: Measurement coordinate Y ascending
5: Measurement coordinate Y descending
137 Search No. Set/Get 0 to 31
