Omron fh-3 series User Manual

Shape Search IIFH/FZ5 Processing Item Function Reference Manual
167
2
Inspecting and Measuring
*1: The reference coordinates based on the selection in the Method area of the [Ref.setting] tab can be Get only.
*2: The reference coordinates based on the selection of Numerical in the Method area of the [Ref.setting] tab can be Set/Get.
138
Judgement upper limit for
correlation value
Set/Get 0 to 100
139
Judgement lower limit for
correlation value
Set/Get 0 to 100
140
Judgement upper limit for
nu
mber of detections
Set/Get 0 to 32
141
Judgement lower limit for
nu
mber of detections
Set/Get 0 to 32
142
Judgement upper limit for
me
a
surement coordinate X
Set/Get -99999.9999 to 99999.9999
143
Judgement lower limit for
me
asurement coordinate X
Set/Get -99999.9999 to 99999.9999
144
Judgement upper limit for
me
asurement coordinate Y
Set/Get -99999.9999 to 99999.9999
145
Judgement lower limit for
me
a
surement coordinate Y
Set/Get -99999.9999 to 99999.9999
146
Judgement upper limit for
me
asurement angle
Set/Get -180 to 180
147
Judgement lower limit for
me
asurement angle
Set/Get -180 to 180
161 Number of detections Set/Get 0 to 32
168 Multiple output Set/Get
0: OFF
1: ON
171
Save the model registration
imag
e
Se
t/Get
0: None
1: Save
1000 + NN (NN = 0 to 31) Correlation value Get only 0 to 100
1100 + NN (NN = 0 to 31) Measurement X Get only -99999.9999 to 99999.9999
1200 + NN (NN = 0 to 31) Measurement Y Get only -99999.9999 to 99999.9999
1300 + NN (NN = 0 to 31) Measurement angle Get only
-180 to 180
No. Data name Set/Get Data range
