IntersectionFH/FZ5 Processing Item Function Reference Manual
301
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Intersection)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Measurement items
Character
string
Description
Judge JG Judgement result
Intersection coordinate X X X coordinate of intersection
Intersection coordinate Y Y Y coordinate of intersection
Angle TH Angle between two lines
Reference X SX X coordinate of the reference coordinates
Reference Y SY Y coordinate of the reference coordinates
Peak edge position X of line 0 PEEKX0
X coordinate of the edge of line 0 that is th
e fu
rthest from the start point of
the measurement region
Peak edge position Y of line 0 PEEKY0
Y coordinate of the edge of line 0 that is th
e furthest from the start point of
the measurement region
Bottom edge position X of line
0
BOTTOMX0
X coordinate of the edge of line 0 that i
s
the closest from the start point of
the measurement region
Bottom edge position Y of line
0
BOTTOMY0
Y coordinate of the edge of line 0 that i
s the closest from the start point of
the measurement region
Edge position X Ave. of line 0 AVEX0 The average of X coordinates of all the edges of line 0
Edge position Y Ave. of line 0 AVEY0 The average of Y coordinates of all the edges of line 0
Long distance Max. of line 0 PMAXD0
The maximum distance between the approximate line and edge position
of
line 0 (plus direction)
Long distance Min. of line 0 PMIND0
The minimum distance between the approximate line and edge position
of
line 0 (plus direction)
Short distance Max. of line 0 BMAXD0
The maximum distance between the approximate line and edge position
of
l
ine 0 (minus direction)
Short distance Min. of line 0 BMIND0
The minimum distance between the approximate line and edge position
of
line 0 (minus direction)
Deviation of line 0 DEV0 Concave and convex deviation of line 0
Angle of line 0 LINETH0 The line 0's inclination against the measurement region
Lost point count of line 0 LOST0 Number of parts for which the detection
of edges of line 0 has failed
Line parameter A of line 0 A0 A in the expression for the approximate line of line 0 AX + BY + C = 0.
Line parameter B of line 0 B0 B in the expression for the approximate line of line 0 AX + BY + C = 0.
Line parameter C of line 0 C0 C in the expression for the approximate line of line 0 AX + BY + C = 0.
Peak edge position X of line 1 PEEKX1
X coordinate of the edge of line 1 that is the furthest from the start point of
the measurement region
Peak edge position Y of line 1 PEEKY1
Y coordinate of the edge of line 1 that is th
e fu
rthest from the start point of
the measurement region
Bottom edge position X of line
1
BOTTOMX1
X coordinate of the edge of line 1 that i
s the closest from the start point of
the measurement region
Bottom edge position Y of line
1
BOTTOMY1
Y coordinate of the edge of line 1 that i
s
the closest from the start point of
the measurement region
Edge position X Ave. of line 1 AVEX1 The average of X coordinates of all the edges of line 1
Edge position Y Ave. of line 1 AVEY1 The average of Y coordinates of all the edges of line 1
